MADEIRA ARCHIPELAGO

Aeronautical Chart ICAO
1:500 000 and 1:250 000

(2418/2419)
Scale 1:500 000 and 1:250 000
3rd EDITION

Print format

Folded dimensions 16.5 cm x 24 cm, open 67 cm x 96 cm:

• Coverage between latitudes 33°55’N and 29°40’N and longitudes 018°20’W and 015°00’W
• Scale 1:500 000 and 1:250 000
• Lambert Conformal Conic Projection, standard parallels 33°18’ and 32°18’
• Ellipsoid WGS84
• Horizontal datum, WGS84
• Vertical datum, Mean Sea Level
• Printed on wear and water-resistant film.
  For markings and notes use a soft-lead, water-soluble, non-drying dermatographic pencil, that easily erases with a wet tissue or cloth. Do not use pens or ink markers, alcohol or other solvents or rubber erasers.

Digital format

3 files stored in a USB pen drive:

• ANC_Portugal_Madeira_500k_GeoTIFF_2edition (GeoTIFF – smartphones, tablets, GIS software)
• ANC_Portugal_Madeira_500k_KMZ_2edition (KMZ – Google Earth)
• ANC_Portugal_Madeira_500k_Geospatial_PDF_2edition (Geospatial PDF file – selectable feature layers)
